Baoji Lyne Metals Co.,Ltd

Features:Corrosion Resistant Bus Bar, Acid&Alkali resistance,Complete Metallurgical Bond,Superior Conductivity,Environmentally Friendly,Custom Thickness Available.

Technology:Explosion Rolling

Application: Electrolysis, Plating, Hydrometallurgy,Oil and Chemcial indurty, etc

Ultimate Strength (≥ MPa):220--400     material:copper as substrate

Titanium Clad Copper,Titanium Clad Aluminum,Stainless Clad Copper,Zirconium Clad Copper,Titanium Clad Nickel etc.

Features:Corrosion Resistant Bus Bar, Acid&Alkali resistance,Complete Metallurgical Bond,Superior Conductivity,Environmentally Friendly,Custom Thickness Available.

Technology:Explosion Rolling

Application: Electrolysis, Plating, Hydrometallurgy,Oil and Chemcial indurty, etc

 Custom Thickness Available

 Specifications for typical consigurations are show above,However,

 titanium, material-No. 37025 or 3.7035, DIN 17850, ASTM B 265 Grade 1 or 2

 Core    material acc. to EN 13601, CU-HCP, CW021A, ANSI / ASTM B 244, UNS No.C 10300

 Cu-HCP          ≥99 % IACS   58 MS/m
 Relation to copper
Titanium                    1 : 26 at  20° C
                                  1 : 66 at 400° C

Stainless steel            1 : 42

TiAI6V4                   1 : 100
Material                      Electrical conductivity in mS / m

Titanium / Cu  on titanium                       2.153

Titanium grade 2  1.5 mm sheet               2.110

Titanium grade 2                                       2.240

TiAI VT 01  12.7 x 6.3 mm                       1.645

TiAI VT 01  25.4 x 12.7 mm                    1.819

TiAI6V4                                                    0.58

Copper                                                       58.0

CuCoBe                                                     30.0

CuCrZr                                                      49.0

W/Cu  75/25                                              19 – 24.0

CuP6                                                          4.0

AI                                                              28.65

AIMgCuPb                                               20.45
